Java爬虫 web版

本文最后更新于 1926 天前，其中的信息可能已经有所发展或是发生改变。

Github

https://github.com/EchoGroot/fourth_spring_simfyspider.git

目的

运用
spring mvc ：WebMVC框架完成从请求到java 1.Controller 2.Model 3.View
hibernate-jpa / spring-data-jpa：ORM : 对象关系映射
spring ：无侵入、轻量级、无缝集成其他框架
spring boot：极度简化spring配置，快速上手开发，提供诸多产品级功能
搭建
利用url传参，并开发持久层，将爬取的数据存储到数据库

分层

web ：接收请求、转换、页面展示等相关功能
service ：服务层、提供查询、抓取等功能实现
dal ：数据访问层，数据持久化相关功能
domain：领域模型层，模型对象
common：通用工具类

结构

LinkStore 管理未访问及已访问的队列
PageVisitor 访问URL得到页面
PageParser 解析网页，得到内容
PageRepository 页面仓储服务，保存数据及文件
SimfySpider 爬虫，组装组件
App 测试类

运行

运行程序访问 http://localhost:8080/crawl?seed=http://news.cqjtu.edu.cn/list.jsp?urltype=tree.TreeTempUrl%26wbtreeid=1021
注意：参数seed里面的url地址不能含有转义字符如& 需要用%26编码代替

结果

配置数据源
配置jpa

# 数据源配置：使用哪个数据库
spring.datasource.url=jdbc:mysql://127.0.0.1:3306/cqjtu?useUnicode=true&characterEncoding=utf-8&serverTimezone=UTC
spring.datasource.username=root
spring.datasource.password=********
spring.datasource.driver-class-name=com.mysql.cj.jdbc.Driver
# jpa配置
# 控制hibernate的ddl生成策略，create为每次创建
spring.jpa.hibernate.ddl-auto=update
#<property name="hibernate.dialect">org.hibernate.dialect.MySQL5Dialect</property>
spring.jpa.hibernate.dialect=org.hibernate.dialect.MySQL5Dialect
# 是否打印SQL
spring.jpa.show-sql=true
# 日志级别配置
logging.level.org.springframework.boot=INFO

代码

CharsetDetector

/*
 * Copyright (C) 2014 hu
 *
 * This program is free software; you can redistribute it and/or
 * modify it under the terms of the GNU General Public License
 * as published by the Free Software Foundation; either version 2
 * of the License, or (at your option) any later version.
 *
 * This program is distributed in the hope that it will be useful,
 * but WITHOUT ANY WARRANTY; without even the implied warranty of
 * MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
 * GNU General Public License for more details.
 *
 * You should have received a copy of the GNU General Public License
 * along with this program; if not, write to the Free Software
 * Foundation, Inc., 59 Temple Place - Suite 330, Boston, MA  02111-1307, USA.
 */
package com.fourth.spring.simfyspider.common;


import org.mozilla.universalchardet.UniversalDetector;

import java.io.UnsupportedEncodingException;
import java.util.regex.Matcher;
import java.util.regex.Pattern;

/**
 * 字符集自动检测
 *
 * @author hu
 */
public class CharsetDetector {

    //从Nutch借鉴的网页编码检测代码
    private static final int CHUNK_SIZE = 2000;

    private static Pattern metaPattern = Pattern.compile(
            "<meta\\s+([^>]*http-equiv=(\"|')?content-type(\"|')?[^>]*)>",
            Pattern.CASE_INSENSITIVE);
    private static Pattern charsetPattern = Pattern.compile(
            "charset=\\s*([a-z][_\\-0-9a-z]*)", Pattern.CASE_INSENSITIVE);
    private static Pattern charsetPatternHTML5 = Pattern.compile(
            "<meta\\s+charset\\s*=\\s*[\"']?([a-z][_\\-0-9a-z]*)[^>]*>",
            Pattern.CASE_INSENSITIVE);

    //从Nutch借鉴的网页编码检测代码
    private static String guessEncodingByNutch(byte[] content) {
        int length = Math.min(content.length, CHUNK_SIZE);

        String str = "";
        try {
            str = new String(content, "ascii");
        } catch (UnsupportedEncodingException e) {
            return null;
        }

        Matcher metaMatcher = metaPattern.matcher(str);
        String encoding = null;
        if (metaMatcher.find()) {
            Matcher charsetMatcher = charsetPattern.matcher(metaMatcher.group(1));
            if (charsetMatcher.find()) {
                encoding = new String(charsetMatcher.group(1));
            }
        }
        if (encoding == null) {
            metaMatcher = charsetPatternHTML5.matcher(str);
            if (metaMatcher.find()) {
                encoding = new String(metaMatcher.group(1));
            }
        }
        if (encoding == null) {
            if (length >= 3 && content[0] == (byte) 0xEF
                    && content[1] == (byte) 0xBB && content[2] == (byte) 0xBF) {
                encoding = "UTF-8";
            } else if (length >= 2) {
                if (content[0] == (byte) 0xFF && content[1] == (byte) 0xFE) {
                    encoding = "UTF-16LE";
                } else if (content[0] == (byte) 0xFE
                        && content[1] == (byte) 0xFF) {
                    encoding = "UTF-16BE";
                }
            }
        }

        return encoding;
    }

    /**
     * 根据字节数组，猜测可能的字符集，如果检测失败，返回utf-8
     *
     * @param bytes 待检测的字节数组
     * @return 可能的字符集，如果检测失败，返回utf-8
     */
    public static String guessEncodingByMozilla(byte[] bytes) {
        String DEFAULT_ENCODING = "UTF-8";
        UniversalDetector detector = new UniversalDetector(null);
        detector.handleData(bytes, 0, bytes.length);
        detector.dataEnd();
        String encoding = detector.getDetectedCharset();
        detector.reset();
        if (encoding == null) {
            encoding = DEFAULT_ENCODING;
        }
        return encoding;
    }

    /**
     * 根据字节数组，猜测可能的字符集，如果检测失败，返回utf-8
     * @param content 待检测的字节数组
     * @return 可能的字符集，如果检测失败，返回utf-8
     */
    public static String guessEncoding(byte[] content) {
        String encoding;
        try {
            encoding = guessEncodingByNutch(content);
        } catch (Exception ex) {
            return guessEncodingByMozilla(content);
        }

        if (encoding == null) {
            encoding = guessEncodingByMozilla(content);
            return encoding;
        } else {
            return encoding;
        }
    }
}

NewsRepository

package com.fourth.spring.simfyspider.dal;

import com.fourth.spring.simfyspider.domain.News;
import com.fourth.spring.simfyspider.domain.Page;
import org.springframework.data.jpa.repository.JpaRepository;

public interface NewsRepository extends JpaRepository<News,Integer> {

}

News

package com.fourth.spring.simfyspider.domain;

import javax.persistence.*;

@Table(name="ss_news")
@Entity
public class News {
    @Id
    @GeneratedValue(strategy = GenerationType.IDENTITY)
    private String newsId;
    private String title;
    private String url;
    private String content;
    private String summary;

    public String getTitle() {
        return title;
    }

    public void setTitle(String title) {
        this.title = title;
    }

    public String getUrl() {
        return url;
    }

    public void setUrl(String url) {
        this.url = url;
    }

    public String getContent() {
        return content;
    }

    public void setContent(String content) {
        this.content = content;
    }

    public String getSummary() {
        return summary;
    }

    public void setSummary(String summary) {
        this.summary = summary;
    }
    //alt+insert

    @Override
    public String toString() {
        return "News{" +
                "title='" + title + '\'' +
                ", url='" + url + '\'' +
                ", content='" + content + '\'' +

                '}';
    }

    public String getNewsId() {
        return newsId;
    }

    public void setNewsId(String newsId) {
        this.newsId = newsId;
    }
}

Page

package com.fourth.spring.simfyspider.domain;

import com.fourth.spring.simfyspider.common.CharsetDetector;
import org.jsoup.Jsoup;
import org.jsoup.nodes.Document;

import java.io.UnsupportedEncodingException;

/**
 * 对页面内容的封装
 * @author Administrator
 *
 */
public class Page {

    private byte[] content;
    private String url;
    private Document doc;
    private String html;
    private String contentType;
    private String charset;

    public Page(byte[] content,String url ,String contentType){
        this.content=content;
        this.url=url;
        this.contentType=contentType;
    }

//alt+insert
    public byte[] getContent() {
        return content;
    }

    public void setContent(byte[] content) {
        this.content = content;
    }

    public String getUrl() {
        return url;
    }

    public void setUrl(String url) {
        this.url = url;
    }

    public void setHtml(String html) {
        this.html = html;
    }

    public String getContentType() {
        return contentType;
    }

    public void setContentType(String contentType) {
        this.contentType = contentType;
    }

    /**
     * 返回网页的源码字符串
     *
     * @return 网页的源码字符串
     */
    public String getHtml() {
        if (html != null) {
            return html;
        }
        if (content == null) {
            return null;
        }
        if(charset==null){
            charset = CharsetDetector.guessEncoding(content); // 根据内容来猜测 字符编码
        }
        try {
            this.html = new String(content, charset);
            return html;
        } catch (UnsupportedEncodingException ex) {
            ex.printStackTrace();
            return null;
        }
    }

    /*
     *  得到文档
     * */
    public Document getDoc(){
        if (doc != null) {
            return doc;
        }
        try {
            this.doc = Jsoup.parse(getHtml(), url);
            return doc;
        } catch (Exception ex) {
            ex.printStackTrace();
            return null;
        }
    }
}

LinkStore

package com.fourth.spring.simfyspider.service.spider;

import org.springframework.stereotype.Component;

import java.util.HashSet;
import java.util.LinkedList;
import java.util.Queue;
import java.util.Set;

/**
 *
 * @author Administrator
 *
 */
@Component
public class LinkStore {
	private Set<String> visitedLinks = new HashSet<>();
	private Queue<String> unVisitedLinkQueue = new LinkedList<>();
	public void addUnVisitLink(String url) {
		System.out.println("添加未访问"+url);
		if(url!=null&&!visitedLinks.contains(url)&&!unVisitedLinkQueue.contains(url)) {
			unVisitedLinkQueue.add(url);
		}
	}

	public void addVisited(String url) {
		System.out.println("添加已访问"+url);

		visitedLinks.add(url);
	}


	public boolean isVisited(String url) {
		return visitedLinks.contains(url)||visitedLinks.contains(url.concat("/"));
	}


	public boolean isUnVisitedEmpty() {
		return unVisitedLinkQueue.isEmpty();
	}

	public String getFirst() {
		return unVisitedLinkQueue.poll();
	}
}

PageParser

package com.fourth.spring.simfyspider.service.spider;

import com.fourth.spring.simfyspider.domain.Page;
import org.jsoup.nodes.Element;
import org.jsoup.select.Elements;
import org.springframework.stereotype.Component;

import java.util.HashSet;
import java.util.Set;

/**
 * 解析页面
 * @author Administrator
 *
 */
@Component
public class PageParser {
	public Set<String> getLinks(Page page, String cssSelector){
		System.out.println("开始解析获得连接");

		Elements elements = page.getDoc().select(cssSelector);
		Set<String> links = new HashSet<>();
		for(Element e : elements){
			String link = e.absUrl("href");
			links.add(link);
		}
		return links;
	}

	/**
	 * 获得所有的目标元素
	 * @param page
	 * @param cssSelectors
	 * @return
	 */
	public Elements getTargetElements(Page page ,String... cssSelectors){
		Elements result = new Elements();
		for(String s : cssSelectors) {
			Elements elements = page.getDoc().select(s);
			if(elements!=null&&elements.size()>0) {
				result.addAll(elements);
			}
		}
		return result;
	}

}

PageVisitor

package com.fourth.spring.simfyspider.service.spider;

import com.fourth.spring.simfyspider.domain.Page;
import org.apache.http.Header;
import org.apache.http.client.config.RequestConfig;
import org.apache.http.client.methods.CloseableHttpResponse;
import org.apache.http.client.methods.RequestBuilder;
import org.apache.http.impl.client.CloseableHttpClient;
import org.apache.http.impl.client.DefaultHttpRequestRetryHandler;
import org.apache.http.impl.client.HttpClients;
import org.apache.http.util.EntityUtils;
import org.springframework.stereotype.Component;

import java.io.IOException;

/**
 *
 * @author Administrator
 *
 */
@Component
public class PageVisitor {

	/**
	 * 访问网页
	 * @param url
	 * @return
	 */
	public Page visit(String url) {
		//1. 创建客户端
		// 配置httpclient
		RequestConfig config = RequestConfig.custom()
				.setConnectTimeout(50000)
				.setSocketTimeout(50000)
				.setConnectionRequestTimeout(10000).build();

		CloseableHttpClient client = HttpClients.custom()
				.setDefaultRequestConfig(config)
				.setRetryHandler(new DefaultHttpRequestRetryHandler())
				//设置UserAgent，避免网站出现403
				.setUserAgent("Mozilla/5.0(Windows;U;Windows NT 5.1;en-US;rv:0.9.4)")
				.build();

		try {
			//2.执行请求
			System.out.println("url:"+url);
			CloseableHttpResponse response = client.execute(RequestBuilder.get(url).build());
			//3.解析响应
			if(response.getStatusLine().getStatusCode()!=200){
				System.out.println("请求"+url+"失败");
			}else{
				//将响应转换成内部的page对象
				byte[] responseBody = EntityUtils.toByteArray(response.getEntity());
				Header contentType = response.getEntity().getContentType();
				Page p = new Page(responseBody,url,contentType.getName());
				return p;
			}
		} catch (IOException e) {
			e.printStackTrace();
		}finally {
			try {
				client.close();
			} catch (IOException e) {
				e.printStackTrace();
			}
		}

		return null;
	}

}

SimfySpider

package com.fourth.spring.simfyspider.service.spider;

import com.fourth.spring.simfyspider.dal.NewsRepository;
import com.fourth.spring.simfyspider.domain.News;
import com.fourth.spring.simfyspider.domain.Page;
import org.jsoup.nodes.Element;
import org.jsoup.select.Elements;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

import java.util.ArrayList;
import java.util.List;
import java.util.Set;

@Service
public class SimfySpider {
	@Autowired
	PageVisitor visitor;
	@Autowired//自动生成对象 以前是PageParser parser=new PageParser();
	PageParser parser;
	@Autowired
	NewsRepository repo;

	public void crawling(String seed) {
		List<News> newsList = new ArrayList<>();
		//初始化LinkStore
		LinkStore linkStore = new LinkStore();
		//把种子URL加入未访问队列
		System.out.println("seed"+seed);
		linkStore.addUnVisitLink(seed);
		while(!linkStore.isUnVisitedEmpty()) {
			//得到链接
			String url = linkStore.getFirst();
			//访问页面
			Page page = visitor.visit(url);
			//得到链接，存入未访问队列
			//System.out.println("page.getHtml()"+page.getHtml());
			Set<String> links = parser.getLinks(page,".pagebar .nowrap a");
			System.out.println("111");
			System.out.println(links.size());
			for(String s: links) {
				System.out.println("112");
				System.out.println("0000"+s);
				if(!linkStore.isVisited(s)) {
					linkStore.addUnVisitLink(s);
				}
//
			}
			//得到需要的内容clearfix
			//System.out.println(page.getHtml());
			Elements elements = parser.getTargetElements(page,".right-title");//.info-box .title
			System.out.println("elements.text()"+elements.text());
			//Elements elements = parser.getTargetElements(page,".clearfix");
			for (Element e :elements){
				System.out.println(elements.size());
				Element element = e.select("a").first();
				News news = new News();
				System.out.println("element.text()"+element.text());
				news.setTitle(element.text());
				news.setUrl(element.absUrl("href"));

				//Element summaryElement = e.select(".summary").first();
				//news.setSummary(summaryElement.text());

				//获取内容页的操作
				String content = null;
				Page contentPage = visitor.visit(news.getUrl());
				Elements contentElements = parser.getTargetElements(contentPage,".article-title");
				//System.out.println("123  "+contentElements.size());
				if(contentElements!=null&&contentElements.size()>0){
					//System.out.println("123"+contentElements.html());
					content = contentElements.first().text();
					news.setContent(content);
				}
				newsList.add(news);
				System.out.println(news);
			}

			//添加已访问
			linkStore.addVisited(url);
			//保存文件
			repo.saveAll(newsList);
		}
	}
}

CrawlingController

package com.fourth.spring.simfyspider.web;

import com.fourth.spring.simfyspider.service.spider.SimfySpider;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.stereotype.Repository;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;

@Controller
public class CrawlingController {
    @Autowired
    private SimfySpider simfySpider;
    @RequestMapping("crawl")//地址映射
    @ResponseBody
    public String crawl(String seed){
        simfySpider.crawling(seed);
        return "success";
    }
}

Post Views: 641
